The 1200°C hydrogen atmosphere pit furnace is designed for heat treatment of tungsten and molybdenum materials, ensuring clean processing and stable material properties
name | Specifications and Models | Furnace dimensions (length, width, height) in mm | Temperature control area | power kW |
Vacuum atmosphere pit furnace | GWL-1200ZQJ/D730/1000 | D800×1300, effective temperature range D730×1000 (±5 degrees). | Three independent temperature control systems (upper, middle, and lower) | 105 |
vacuum system | 25L/s | Includes controls, including air intake and piping. | ||
Hydrogen combustion | Automatic combustion | |||
platform | 2*2*2 | Includes stairs | ||
Furnace tube | 310S | Wall thickness 15mm, lid thickness 25mm | single set | |
| Production cycle | Delivery in 30-40 days | |||
