High-Temperature Ceramic Roller Kiln for Continuous Sintering

GWDL-SRK-30-4000 ceramic roller kiln is a continuous high-temperature firing furnace designed for precision sintering of ceramic components. With an advanced modular design, the system integrates high-efficiency heating, uniform temperature control, and optimized roller transmission, suitable for applications in electronic ceramics, structural ceramics, magnetic materials, and other fields requiring consistent thermal processing. The roller kiln is customized based on user specifications, offering flexibility in furnace length, heating zones, roller materials, and control systems.

Technical Specifications

Parameter	Specification
Model	GWDL-SRK-30-4000
Max Temperature	1350°C
Working Temperature	1280°C
Power Supply	AC 380V / 3-phase
Rated Power	120 kW
Roller Length	2300 mm
Roller Material	Stainless steel rod / Ceramic rod / Si₃N₄ recrystallized rod
Heating Element	High-efficiency SiC heating rods (or MoSi₂ optional)
Refractory Material	Alumina fiberboard, multilayer energy-saving insulation
Temperature Zones	6–10 independently controlled zones
Temperature Control	PID control + SCR; independent points per zone
Temperature Accuracy	±1°C
Temperature Uniformity	Top & bottom difference ≤ ±5°C
Speed Range	120–1000 mm/min (inverter-controlled)
Thermocouple Type	K-type, multi-point measurement
Control Cabinet	Independent; PLC + HMI (optional remote control)
Customization	Support process-based custom design
Packaging	Composite wood packaging (fumigation-free)

Product Features

Rapid & Uniform Heating

Dual-sided heating above and below the roller table ensures uniform temperature distribution.
Heating zones can be finely controlled to maintain minimal top-bottom deviation (≤5°C).
High-efficiency SiC or MoSi₂ elements ensure reliable performance at high temperatures.

Energy-Saving Structure

Roller kilns require no kiln cars or saggers; only refractory backing plates are needed.
Reduced heat loss leads to energy savings and lower operating costs.

Transmission System

Equipped with a precision helical gear mechanism, minimizing transmission deviation.
Features include small footprint, high torque, smooth startup, and reliable motion.

Full Automation Ready

Independent control cabinet integrates temperature, roller speed, and alarms.
Optional touch screen + PLC interface supports data logging, auto-start, and remote monitoring.
Roller movement and heating profile are programmable for batch or continuous production.

Modular and Custom Design

Designed per customer’s process parameters: sintered material, temperature, and throughput.
GWDL engineers provide tailored solutions, balancing thermal uniformity, environmental protection, and automation.
